Granite Cutting Wastewater Dewatering Hydraulic Cylinder Pressing Industrial Filter Press

Granite Cutting Wastewater Dewatering Hydraulic Cylinder Pressing Industrial Filter Press

    • Granite Cutting Wastewater Dewatering Hydraulic Cylinder Pressing Industrial Filter Press
    • Granite Cutting Wastewater Dewatering Hydraulic Cylinder Pressing Industrial Filter Press
    • Granite Cutting Wastewater Dewatering Hydraulic Cylinder Pressing Industrial Filter Press
    • Granite Cutting Wastewater Dewatering Hydraulic Cylinder Pressing Industrial Filter Press
    • Granite Cutting Wastewater Dewatering Hydraulic Cylinder Pressing Industrial Filter Press
  • Granite Cutting Wastewater Dewatering Hydraulic Cylinder Pressing Industrial Filter Press

    Product Details:

    Place of Origin: China
    Brand Name: TOPER
    Certification: CE
    Model Number: XY50/870-30U

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiable
    Price: Negotiable
    Packaging Details: Export standard wooden package.
    Delivery Time: 10-15 working days after receive your payment
    Payment Terms: L/C, T/T, D/A, D/P, Western Union
    Supply Ability: 500 sets per month for this industrial filter press
    Contact Now
    Detailed Product Description
    Filtration Area: 50m2 PP Plate Dimension: 870*870mm
    Filtration Capacity: 748L Plate Pieces: 38pcs
    Filtrating Pressure: 0.6Mpa Cake Discharge: Manually
    Motor: 2.2kw Compression: Hydraulic Unit
    Feeding Type: Pump Feeding Liquid Discharge Type: Open Flow Or Close Flow
    Filter Medium: Filter Cloth Color: Blue Or Customized
    Conditon: New
    Highlight:

    filter presses for sludge treatment

    ,

    filter press equipment

    Granite Cutting Wastewater Dewatering Hydraulic Cylinder Pressing Industrial Filter Press



    Industrial filter press can be divided into plate and frame type and chamber type. it is one kind of intermittent filter equipment. It is used for solid-liquid separation of various suspensending liquid. Filter plate are pressed by pressing system, and then suspension is pumped into the filter chamber. solid particles and liquid is separated through gilter cloth. This automatic fitler press is simple in structure, but in good separation effects. conventient in use, and widely used in the below industries:



    1. Chemicals Industry Dewatering - Pigments, Organic Polymers, Silica Gel, Organic Dyes, Carbon Fines, Brine Sludge, Ethanol Slops, Phosphoric Acid, Explosives Wastes, Paint Sludge, Latex, Pesticide Wastes.

    2. Electronics Industry Dewatering - Metal Hydroxide Sludge, R.O. Sludge.

    3. Food Industry Dewatering - Brewery Mash, Sugar Carbonation Sludge, Wine Lees, Yeast, Apple Juice Polishing, Meat Packaging Wastes, Scrap Candy, Palm Oil.

    4. Hazardous Waste Remediation - Soil Washing, Landfill Leachate, Heavy Metals Precipitation, Metals, Metalworking, Transportation Industries Dewatering - Steel Rolling Mill Waste, Foundry Sludge, Plating Wastes, Paint Spray Booth Waste, Oily Waste.

    5. Mining Industry Dewatering - Titanium Dioxide, Clay, Copper, Zinc, Lead, Gold , Mineral Tailings, Coal Tailings, Acid Mine Drainage, Ready Mix Washout.

    6. Municipal Waste Dewatering - Primary, Secondary Raw and Digested Sludge, Teritary Lime Sludge.

    7. Pulp & Paper Filtration - Recausticizing Wastes, Biological Waste Treatment Sludge, Secondary Fiber, De-inking Waste Recovery, granite or other ores cutting waste water.

    8. Oil & Petrochemical Recovery - Drilling & Completion Fluids, Slop Oil Recovery.

    9. Pharmaceuticals, Toiletries, Cosmetics Filtration- Biological Treatment Sludge.

    10. Power Industry Dewatering - Cooling Tower Sludge, Scrubber Sludge, Fly Ash, Coal Pile Runoff.

    11. Water Supply Dewatering - Alum, Ferric, Polymer and Softening Sludge, Dy Wash Suspension Filtration.





    Environmentally Friendly Industrial Filter Press For Granite Cutting Wastewater Dewatering consists of beam, filte plate, hydraulic system(hydraulic unit), filter cloths, control cabinet.



    1. Beam, High quality carbon steel Q345B and processed with sand blasting to remove rust and oxide skin, then painted by epoxy primer to get higher intensity and corrosion resistance. here with honey used, to satisfy food industry used we can covered with the beam with stainless steel.

    2. Filter plate,material is glass fiber polypropylene with acid & alkali resistance, anticorrosion, innocuity, tasteless, light weight and high strength. also with the glass fiber poplypropylene material, it can bear about 1.5Mpa pressure, which common filter press material of polypropylene is about 0.6Mpa.

    3. Filter cloths, High quality polypropylene acid and alkali proof or high quality polyester acid.

    4. Hydraulic unit, China brand famous pumps and hydraulic valve; Carbon steel bending welding, sealing, air filtration external oil pump, cooling effect is good, maintenance is convenient; High and low pressure oil pipe for gb soft connection

    5. Electric control cabinet, PLC control cabinet with Siemens brand or schneider brand Electrical components, Split type or can be fixed on the beam.





    Technical parameter:



    Type

    Filter area

    (m2)

    Filter plate size(mm)

    Filter cake thickness

    (mm)

    Filter chamber volume

    (L)

    Filter plate number

    (PCS)

    Filtrating pressure

    (MPa)

    Motor power

    (KW)

    Weight

    (Kg)

    Dimension (mm)

    (L×W×H)

    XY4/450-30U 4 450×450 30 60 9 0.6 2.2 860 1950×700×900
    XY6/450-30U 6 91 14 910 2200×700×900
    XY8/450-30U 8 121 19 960 2450×700×900
    XY10/450-30U 10 151 24 1010 2700×700×900
    XY12/450-30U 12 182 29 1060 2950×700×900
    XY15/450-30U 15 225 36 1130 3300×700×900
    XY16/450-30U 16 243 39 1160 3450×700×900
    XY15/630-30U 15 630×630 226 18 1725 2640×900×1100
    XY20/630-30U 20 297 24 1993 3940×900×1100
    XY30/630-30U 30 452 37 2360 3590×900×1100
    XY40/630-30U 40 595 49 2788 4300×900×1100
    XY30/800-30U 30 800×800 460 23 2170 3700×1400×1300
    XY40/800-30U 40 595 30 2450 4300×1400×1300
    XY50/800-30U 50 748 38 2700 4840×1400×1300
    XY60/800-30U 60 902 46 2980 5440×1400×1300
    XY70/800-30U 70 1056 54 3250 6040×1400×1300
    XY30/870-30U 30 870×870 460 23 2580 3180×1200×1300
    XY40/870-30U 40 595 30 2925 3570×1200×1300
    XY50/870-30U 50 748 38 3318 4110×1200×1300
    XY60/870-30U 60 902 46 3712 4550×1200×1300
    XY70/870-30U 70 1056 54 4106 4990×1200×1300
    XY80/870-30U 80 1210 62 4561 5430×1200×1300
