| Place of Origin: | China |
| Brand Name: | TOPER |
| Certification: | CE |
| Model Number: | GF125 |
| Minimum Order Quantity: | 1SET |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export standard wooden package. |
| Delivery Time: | 10-15 working days after receive your payment |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union |
| Supply Ability: | 60 sets per month for this tubular centrifuge |
| Drum Diameter: | 125mm | Drum Volume: | 8L |
|---|---|---|---|
| Drum Rotate Speed: | 15000r/min | Separation Factor: | 15750 |
| Water Flow Capacity: | 1500kg/h | Power: | 3.0kw |
| Motor: | Customized | Material: | Stainless Steel |
| Condition: | New | Type: | Tubular Centrifuge |
| Function: | 2 Phase Or 3 Phase Separation | Feeding Method: | Manual Or Pump Feeding |
| Weight: | 610KGS |
Brief introduction of the GF separation type virgin coconut oil tubular centrifuge:
High Speed Tubular Centrifuge, also called Tubular Bowl Separator, is a kind of fine separation equipment suitable for suspensions with thin concentration, fine particles, and small density difference solid-liquid separation, or liquid-liquid-solid separation.
It is indispensable equipment for food, chemical, biological product, fermentation broth, beverages, blood products and other industries. High Speed Tubular Centrifuge working principle is that materials with different specific gravity are subject to different centrifugal forces when rotating at high speed, so as to achieve the purpose of separation.
Tubular centrifuge is mainly divided into clarify series GQ and separation series GF.
GF separation series:
The GF type is mainly used for various difficult-to-separate suspensions in the separation industry, and is especially suitable for liquid-liquid separation with small specific gravity differences and liquid-liquid-solid three-phase separation with a small amount of impurities.
Working principle :
The centrifuge rotates at a high speed to reach a suitable working speed (the speed can be adjusted control panel), and the mixed suspension is continuously fed from the bottom, and the suspension are layered under the action of centrifugal force;
The two liquids in the suspension have a difference in density and are incompatible with each other. The liquid phase spirally rises gradually from bottom to top to the upper part of the rotor. The liquid phase with a smaller density is discharged from the light liquid outlet, and the liquid phase with a larger density is discharged from the heavy liquid outlet;
The solid phase density is the largest, and it will settle inside the bowl. After the solids are collected, turn off the centrifuge, and manually remove the rotor for slag cleaning;
After cleaning the slag, need to re-install the rotor, and then start the next separation process.
Features of High Speed Tubular Centrifuge
Technical parameters:
|
Model |
Drum |
Nozzle diameter |
Productivity( water flow) (kg/h) |
Power |
Weight (kg) |
||||
|
Inner diameter |
Height |
Volume |
Rotary speed |
Separation factor |
|||||
| GF45 | 45 | 280 | 0.4 | 28000 | 19800 | 2,3 | 100 | 0.55 | 90 |
| GF75 | 75 | 450 | 2.2 | 19000 | 15700 | 4,6 | 600 | 1.5 | 300 |
| GF105 | 105 | 730 | 6 | 16300 | 15620 | 6,8 | 1200 | 2.2 | 570 |
| GF125 | 125 | 730 | 7.4 | 15000 | 18000 | 5,8,9 | 1500 | 3.0 | 610 |
| GF150 | 142 | 730 | 10 | 14000 | 15700 | 8,10,12 | 2500 | 3.0 | 665 |
