PLC Controlled Disc Bowl Centrifuge for Chemical and Biological Products

PLC Controlled Disc Bowl Centrifuge for Chemical and Biological Products

    • PLC Controlled Disc Bowl Centrifuge for Chemical and Biological Products
    • PLC Controlled Disc Bowl Centrifuge for Chemical and Biological Products
  • PLC Controlled Disc Bowl Centrifuge for Chemical and Biological Products

    Product Details:

    Place of Origin: China
    Brand Name: TOPER
    Certification: CE
    Model Number: DHC500

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiable
    Price: Negotiable
    Packaging Details: Export standard wooden package.
    Delivery Time: 40 working days after receive your payment
    Payment Terms: L/C, T/T, D/A, D/P, Western Union
    Supply Ability: 30 sets per month for this disc centrifuge
    Contact Now
    Detailed Product Description
    Speed: 6600r/min Dram Diameter: 500mm
    Settlement Area: 35×10^7cm2 Input Capacity For Water: 10t/h
    Motor Power: 11kw Control Method: PLC+Frequency Converter
    Funtion: Solid-liquid,liquid-liquid-solid Separtion Application: Clarification Of Drinks Such As Juice, Vegetable Juice, Tea And Fruit Wine
    Feeding Method: Pump Feeding Or Manual Or Other Operation Principle: Centrifugal Force
    Discharge Way: Automatic Bottom Discharge
    Highlight:

    disc stack separator

    ,

    disk stack centrifuge

    Fruit Juice Clarify Bowl Disk Stack Centrifuge Made by Stainless Steel Material





    The disc centrifuge is a high efficiency, large output, advanced automation equipment.suitable for low solid content slurry, a smaller proportion of poor separation of immiscible liquids, pharmaceutical, food, chemical, biological products, beverage products and other necessary equipment industries.

    According to the separation mode can be divided into three-phase separator (liquid - liquid - solid) disc separatoand two-phase separation (liquid - solid) disc separa.

    While the disc type automatic slag separator in different ways based on, can be divided into manual type automatic slagging disc separator and fully PLC controlled automatic slagging disc separator



    According to the disc separation inside the slag film in different ways, disc separator can be divided into piston slag disc separator with nozzle slag separator, and can be selected according to the characteristics of slag material way.




    Features of the disc centrifuge separator :


    This disc centrifuge separation factor is high, strong separation ability, the model can realize manual slagging or PLC program control time automatic slag, reducing labor intensity, improve work efficiency, hydraulic coupling to replace the traditional friction plate clutch , On-site non-dust clean white health.
    Depending on the need to use automatic or manual operation. Can also achieve long-range self-control operation. Machine structure is simple, easy maintenance.





    This disc centrifuge work wrinciple.

    1. This disc centrifuge is a vertical centrifuge, drum mounted on the top of the vertical axis, driven by the motor drive and high-speed rotation.

    2. The drum has a set of disc-shaped parts that are nested with each other. There is a small gap between the disc and the disc. Suspensions (or emulsions) are fed into the drum from a feed tube located in the center of the drum.

    3. When the suspension (or emulsion) flows through the gap between the discs, the solid particles (or droplets) in the centrifuge under the action of sediment to the disc to form a sediment (or liquid layer).

    4. The sediment slides along the surface of the disc to be separated from the disc and accumulated in the largest diameter portion of the drum, and the separated liquid is discharged out of the drum through the outlet.

    5. The role of the disc is to shorten the settling distance of solid particles (or droplets), expand the settlement area of the drum, the drum in the installation of the disc and greatly improve the production capacity of the separator.

    6. The solids accumulated in the drum are removed manually after the separator has been shut down, or discharged from the drum without stopping the machine.




    This disc centrifuge technical parameters.



    Item DHC300 DHC400 DHC500 DHC550 DHC730

    Drum inner diameter
    (mm)

    300 400 500 550 730
    Drum speed (r/min) 7300 7056 6600 6200 4500
    Settlement area (cm²) 17.2×10^7 28.5×10^7 35×10^7 67×10^7 90×10^7

    Input capacity for water
    (t/h)

    2 5 10 15 35
    Motor power (kw) 4.0 7.5 11 18.5

    55





    PLC Controlled Disc Bowl Centrifuge for Chemical and Biological Products



    Our service:

    1. We have professional person on line to provide you comprehensive.easy-understanding and detail information and technical data about the machine you interested;solve your confusions or questions about the machine
    2. Advise you the most suitable type of machine according to your requirement for your reference
    3. Arrange the schedule if you pay a visit to our factory.
    4. Send our technical engineer to your country for installation ,operation test ,slove questions and so on if required.





    More informaiton about our corporation---Toper



    1. Global Service



    Since 2006,Our equipment has been exported to many countries all over the world such as India, Pakistan, Sri Lanka, Bangladesh, Indonesia, Philippines, Malaysia, Vietnam, Singapore, Turkey, Israel, Burma, Jordan, Yemen, Iran, Iraq, Afghanistan, Syria, Kuwait, Kazakhstan, Qatar, Korea, Azerbaijan, The UAE, Bhutan, Thailand, Lebanon, Bahrain, Egypt, Libya, Ethiopia, Kenya, Somalia, Tanzania, Liberia, Ivory Coast, Ghana, Nigeria, Cameroon, Chad, Guinea, Zambia, Zimbabwe, Malawi, Congo, Gabon, Angola, Mozambique, Botswana, Namibia, South Africa, Argentina, Bahamas, Bolivia, Brazil, Canada, Columbia, Chile, Cuba, Venezuela, Ecuador, Guatemala, Guyana, Honduras, Haiti, Mexico, Peru, Uruguay, Paraguay, Surinam, Australia, Russia etc.



    2. Our Products



    Our manufacturing base of filter equipment mainly produce full automatic or semi-automatic membrane filter press, recessed filter press, belt filter press, centrifuge, etc. All these products are widely used in mining, metallurgy, petroleum, chemical, medicine, textile, printing and dyeing, paper making, food, alcohol, inorganic salt, coal washing, and waste water processing industry.

    We have won good reputation depends on our best qualified products and after-sales service. Warmly welcome new and old friends all over the world to come our company for good cooperation with each other!
