3 Phase Separation High Speed Centrifuge Machine 3.0kw Power For Fruit Juice / Coconut Oil

3 Phase Separation High Speed Centrifuge Machine 3.0kw Power For Fruit Juice / Coconut Oil

    • 3 Phase Separation High Speed Centrifuge Machine 3.0kw Power For Fruit Juice / Coconut Oil
    • 3 Phase Separation High Speed Centrifuge Machine 3.0kw Power For Fruit Juice / Coconut Oil
  • 3 Phase Separation High Speed Centrifuge Machine 3.0kw Power For Fruit Juice / Coconut Oil

    Product Details:

    Place of Origin: China
    Brand Name: TOPER
    Certification: CE
    Model Number: GF125

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiable
    Price: Negotiable
    Packaging Details: Export standard wooden package.
    Delivery Time: 10-15 working days after receive your payment
    Payment Terms: L/C, T/T, D/A, D/P, Western Union
    Supply Ability: 60 sets per month for this tubular centrifuge
    Contact Now
    Detailed Product Description
    Drum Diameter: 125mm Drum Volume: 7.4L
    Drum Rotate Speed: 16000r/min Power: 3.0kw
    Inner Dia.: 125mm Material: Stainless Steel
    Discharge: Manual
    High Light:

    liquid solid separation centrifuge

    ,

    tubular bowl centrifuge

    3 phase separation tubular centrifuge for oil water fruit juice coconut oil





    The tubular centrifuge is a kind of precision equipment, which has specialization, solid and liquid with small solid particles and similar specific gravity, and liquid-liquid solid separation. It is selected by many industries such as food, pharmaceutical, chemical and biological products. device.



    Characteristics

    The clarification effect is achieved by separating the solid phase impurities in the liquid by the machine. It is used to separate various suspensions that are difficult to separate. It is especially suitable for solid-liquid separation with large concentration and small viscosity, fine solid phase particles and small solid-liquid gravity. The solid phase should be taken out after shutdown.

    The main disadvantage of tubular centrifuges is intermittent operation. The drum volume is small. It is necessary to shut down frequently to remove sediment. Therefore, it is necessary to strengthen the separation performance of the tubular centrifuge by strengthening separation theory research and centrifugal separation process research.



    Application

    Tubular Separator is mainly used for separating all kinds of suspension which is difficult to be separated, especially suitable for separation of solid-liquid suspension with light concentration, heavy viscosity, fine particles and very small differential gravity of the two phases. such as clarification of herbs plants extracts, various medicine liquor, liquid medicine, oral liquid, the extraction of paint, dye, as well as various proteins, alga, fruit gels, and purification of rubber solution, coal tar, graphite, saponin, pectin, sirup, vaccine mycelia and all kinds of glucose; refining resin, and latex solution, enzyme (SOD) of oxide, various kinds of albumens, the glucoside of the soap, etc.



    Technical parameters:



    Model Drum Nozzle diameter
    (mm)
    Productivity(water flow) (kg/h) Power
    (KW)
    Weight
    (kg)
    Inner diameter
    (mm)
    Height
    (mm)
    Volume
    (L)
    Rotary speed
    (r/min)
    Separation factor
    GF45 45 280 0.4 28000 19800 2,3 100 0.55 90
    GF75 75 450 2.2 19000 15700 4,6 600 1.5 300
    GF105 105 730 6 16300 15620 6,8 1200 2.2 570
    GF125 125 730 7.4 15000 18000 5,8,9 1500 3.0 610
    GF150 142 730 10 14000 15700 8,10,12 2500 3.0 665





    Company infos.

    1. About TOPER
    Zhengzhou Toper is the leading supplier of industrial equipment in China, and also the professional exporter and service provider of filter and separation equipment.
    2. Global service
    Since 2006, Zhengzhou Toper has supplied products and service to over 200 enterprises of 30 more countries and areas excluding China mainland.
    Southeast Asia: Indonesia, Malaysia, the Philippines, and Thailand; West Asia: Turkey, Uzbekistan and Tajikistan; Northeast Asia: South Korea, Mongolia; Middle East: Israeli, Palestinian, Oman, Bahrain, Iran; Europe: Russia, Italy, Spain, Ukraine, Finland, Poland, Romania; North America: Canada, America; South America: Mexico, Guatemala, Argentina, Brazil, Chile, Peru, Bolivia; Africa: South Africa, Algeria and so on.
    Our products are well-known at home and abroad. We have thousands of users throughout China and clients in the world markets. "Establish TOPER brand for the satisfaction of users" is our persistent pursuit.









    Working principle:



    The principle of the tubular centrifuge is to effectively separate the materials of different specific gravity by the centrifugal force generated by the centrifugal force. According to different separation principles, tubular centrifuges can be divided into two types: clarified type (GQ) and separated type (GF). The main function of clarified tube centrifuge is to treat two separations of liquid and solid; The main function of the centrifuge is to treat liquids in liquid or liquid, liquid and solid phases. The tubular separator consists of a fuselage, a transmission, a drum, and a collecting tray. The inlet bearing housing is composed of a flexible main shaft on the upper part of the drum and a damper bearing on the lower part. The motor passes through the transmission, so that the axis of the drum itself rotates at a high speed, forming a strong centrifugal force field inside the drum, and the material has a bottom inlet inlet. The centrifugal force of the drum causes the liquid to flow upward along the inner wall of the drum, so that the material liquid is separated according to the density difference of the different components, and the layer is discharged from the outlet of the liquid pan.



    The tubular centrifuge is characterized by the separation of solid phase impurities in the liquid by the machine to achieve a clarifying effect. It is used to separate various suspensions that are difficult to separate. It is especially suitable for solid-liquid separation with large concentration and small viscosity, fine solid phase particles and small solid-liquid gravity. The solid phase should be taken out after shutdown.



    Advantage of tubular centrifuge



    Bowl press

    Less noice

    Steady structure

    High speed SNK bearing

    Speed adjustment

    Cooling system








     3 Phase Separation High Speed Centrifuge Machine 3.0kw Power For Fruit Juice / Coconut Oil
