Solid Bowl Basket Centrifuge for Settling Type Industrial Separation

Solid Bowl Basket Centrifuge for Settling Type Industrial Separation

    • Solid Bowl Basket Centrifuge for Settling Type Industrial Separation
    • Solid Bowl Basket Centrifuge for Settling Type Industrial Separation
  • Solid Bowl Basket Centrifuge for Settling Type Industrial Separation

    Product Details:

    Place of Origin: China
    Brand Name: TOPER
    Certification: CE
    Model Number: SS300

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiable
    Price: Negotiable
    Packaging Details: Export standard wooden package.
    Delivery Time: 10-15 working days after receive your payment
    Payment Terms: L/C, T/T, D/A, D/P, Western Union
    Supply Ability: 100 sets per month for this basket centrifuge
    Contact Now
    Detailed Product Description
    Drum Diameter: 300mm Drum Volume: 8L
    Drum Load Limit: 10kgs Drum Rotate Speed: 1900r/min
    Separation: 819 Motor: 0.75kw
    Weight: 130kgs Dimension: 800*620*500mm
    Function: Solid-liquid Separation Material: Stainless Steel Or Other Demand
    Condition: New Type: Settling Type

    Solid Bowl Basket Centrifuge for Settling Type Industrial Separation



    Application scope:

    Suitable for viscosity, hydrophilicity, difficult to separate suspension that containing the fineness of

    particulate or fibrous material; also applies to a paste, separating the solid-

    like materials; and widely used in the textile, food dehydrated .



    Environment, Transport, Storage requirements


    1.Working environment: Temperature 0 ~ 40 ℃; relative humidity less than 85%.

    2.Transportation: centrifuge during shipment, may not roll upside down, not stacked, to prevent

    water intrusion.

    3.Handling: Centrifuge handling process must based on the center of its gravity position

    to determine the lifting force or Scraper point, try to keep the centrifuge in horizontal position

    when lifting or scraper, avoid tumbling and upside down. Site for lifting is the inner side of three

    column foot, Scraper end position for the whole plane.

    4.Storage: centrifuge should be placed no more than 85% relative humidity, temperature 0 ~ 40 ℃,

    no corrosive media cover field.



    Operation principle


    Three-foot upper discharging centrifuge divided into two types according to the separation principle:

    filter type (SS) and settlement type (SSC) ,and the feeding , discharing is intermittent.


    Settlement type (drum cylinder wall without holes)

    This type of centrifuge can be charged before star,and also at medium speed or high speed

    (depending on the physical and chemical properties of the material ) .


    With the centrifugal force,the denser of large granule or liquid is deposited by a drum wall side

    (outer layer), the density of smaller particles or liquid (generally liquid) in the drum stopped by

    the liquid inlet side (inner), due to the continuous feeding, inner lining of the small density of the

    liquid from the mouth of the drum block liquid spill, through the passage between the shell and

    the liquid tank from the liquid collecting pipe discharge, or use the liquid siphon device to outside.


    When the drum precipitation (liquid or solid phase) meet the requirements, stop charging,

    turn off the power, the braking, discharge the cake (or settlement liquid) from the drum, to complete

    a work cycle.



     Technical Parameters Of The Three-foot Structure Solid Bowl Basket Centrifuge,Settling Type Industrial Separator:


    Type Drum

    Separation factor


    Motor power










    Load limit


    Rotation speed


    SS300 300 8 10 1900 819 0.75 130 800×620×500
    SS450 450 20 25 1600 725 1.5 200 980×720×625
    SS600 600 45 80 1450 755 3.0 600 1350×990×750
    SS800 800 98 135 1200 640 5.5 1300 1740×1380×1000
    SS1000 1000 140 195 1000 560 7.5 1500 1950×1560×1050
    SS1200 1200 200 280 800 430 15/11 2030 2370×1600×1000
    SS1500 1500 360 400 650 304 15 4060 2640×1850×1100



    Centrifuge with lid.
