450mm Plate and Frame Stainless Steel Filter Press for Edible Oil Filtration with Plate Material

450mm Plate and Frame Stainless Steel Filter Press for Edible Oil Filtration with Plate Material

    • 450mm Plate and Frame Stainless Steel Filter Press for Edible Oil Filtration with Plate Material
    • 450mm Plate and Frame Stainless Steel Filter Press for Edible Oil Filtration with Plate Material
  • 450mm Plate and Frame Stainless Steel Filter Press for Edible Oil Filtration with Plate Material

    Product Details:

    Place of Origin: China
    Brand Name: TOPER
    Certification: CE
    Model Number: TBSJL400-3

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiable
    Price: Negotiable
    Packaging Details: Export standard wooden package.
    Delivery Time: 30-40 working days after receive your payment
    Payment Terms: L/C, T/T, D/A, D/P, Western Union
    Supply Ability: 20 sets per month for this stainless steel filter press
    Contact Now
    Detailed Product Description
    Filter Area: 3m2 Filter Plate Size: 400*400mm
    Filter Plate And Number Number: 21pcs Filtrating Pressure: 0.3Mpa
    Motor Power: 2.2kw Material: SS304, SS316L.
    Dimension: 1350X660X1300mm
    Highlight:

    filter press machine

    ,

    filter press equipment

    Reliable Stainless Steel Filter Press For Edible Oil Filtration With 450mm Plate and Frame


    It is suitable for various industries: liquid medicine, liquor, beverage, juice, syrup, vinegar, oils, fine chemicals, electroplating etc.

    Specificeation of this stainless steel filter press:

    1. Material: structure-SS304, plate-SS304, SS316L or PP.
    2. Seal material: white silicone rubber, pressure, <0.4Mpa, temperature<120 celsius.
    3. Main dimension: plate thickness, 13mm, individual chamber volume, 4.8L.
    4. Pressing method: Screw/manual hydraulic, others like manual jack, automatic hudraulic system, etc.
    5. Filter media: various filter cloth, filter paper, filter mamebrane, etc.
    6. Filter precision: from 200mesh to 0.22um.

    Technical data of this stainless steel filter press,

    Model

    Filter area
    (m2)

    No. of plate
    (pcs)

    Reference flow (T/h)

    Plate size
    (mm)

    Dimension
    (mm)

    TBSJL400-22151-2400X4001250X660X1300
    TBSJL400-33211-3400X4001350X660X1300
    TBSJL400-44313-4400X4001550X660X1300
    TBSJL400-66454-6400X4001750X660X1300
    TBSJL400-8.58.5616-8400X4002100X660X1300
    TBSJL400-9.59.5718-10400X4002300X660X1300
    TBSJL600-14144110-13600X6001750X870X1350
    TBSJL600-21216115-20600X6002100X870X1350
    TBSJL600-24247120-25600X6002250X870X1350
    TBSJL600-353510125-30600X6002800X870X1350



    Packaging & Shipping
    Reliable and fast package and variety kinds of transportation way to insure you get the goods in time and safely.

    Our Services
    1). We have professional person on line to advise you the most suitable type of machie according to your requirement.
    2). Provide you comprehensive.easy-understanding and detail information and technical data about the machie you interested;solve your confusions or questions about the machine
    3). Arrange the schedule if you pay a visit to our factory
    4). Send our technical engineer to your area guid the installation,debugging ,training workers and solve the problems if rquired.

    Customer satisfaction is our utmost priority thus, customer service team is always on the brink to help our customers with their queries at any time.
    We believe in working as a unit with an attitude of complete trust and understanding and are determined to provide safe, reliable and competitively priced products to our customers.


    Company Information
    1. Manufacture experience,
    Since 1997, we have done a lot of innovation and improvement in the field of filter and separation equipment. We are specialized in design of the filter press according to clients’ requirments, the delivery time of a filter press can be 10 days(if no stock).
    2. Technology capacity,
    We join and make the standard of filter press industry in China, All of our products have CE certificate, also they will be tested before delivery.
    3. Our superiority,
    We are in the first class in the field of filter press of China, more than 250,000 m2 land area and continue developing. Filter areas of filter press widely ranges from 1 m2 to 500 m2, you can always choose a right type.
    4. Best after-sales,
    Supply professional operation training, Timely trouble shooting in 24 hours, we will try our best to solve your problems on the basis of no influence of your equipment working.


    450mm Plate and Frame Stainless Steel Filter Press for Edible Oil Filtration with Plate Material
