630x630mm Size Recessed Plate Chamber Filter Press,Manual Compress Filter Press Equipment

630x630mm Size Recessed Plate Chamber Filter Press,Manual Compress Filter Press Equipment

    • 630x630mm Size Recessed Plate Chamber Filter Press,Manual Compress Filter Press Equipment
    • 630x630mm Size Recessed Plate Chamber Filter Press,Manual Compress Filter Press Equipment
    • 630x630mm Size Recessed Plate Chamber Filter Press,Manual Compress Filter Press Equipment
  • 630x630mm Size Recessed Plate Chamber Filter Press,Manual Compress Filter Press Equipment

    Product Details:

    Place of Origin: China
    Brand Name: TOPER
    Certification: CE
    Model Number: XQ30/630-30U

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiable
    Price: Negotiable
    Packaging Details: Export standard wooden package.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: L/C, T/T, D/A, D/P, Western Union
    Supply Ability: 500 sets per month for this chamber filter press
    Contact Now
    Detailed Product Description
    Filter Area: 30m2 Plate Size: 630*630mm
    Chamber Volume: 452L Plate Pieces: 374pcs
    Filtrating Pressure: 0.6Mpa Compression: Manual
    Feeding Method: Central Feeding Compress Type: Jack Screw
    Filter Cake Discharge Type: Manual Discharge Liquid Discharge Type: Open Flow Or Close Flow
    Plate Material: Reinforced Polypropylene Filter Medium: Filter Cloth
    Conditon: New
    High Light:

    dewatering filter press

    ,

    industrial filter press

    630x630mm Size Recessed Plate Chamber Filter Press,Manual Compress Filter Press Equipment



    We manufacture manual operation recessed chamber filter press(jack filter press) with ratchet closing device. The system consists of ratchet mechanism, pinion and gear wheel. By applying a ratchet lever to the pinion shaft the force is transmitted by small pinion to the larger gear-wheel which provides the final lightning on the plate pack.





    Characteristics:



    The structure is reasonable designed

    The capability is steadily and reliable

    Easy to control and maintain



    It is widely used in areas where solid-liquid separations are needed such as water treatments, sewage processing, etc. It is suitable for small scale filtering areas normally using a low pressure of less than 0.4Mpa.





    Basic technical data:



    Type

    Filter area

    (m2)

    Filter plate size (mm) Cake thickness (mm) Chamber volume (L) Plate number (PCS)

    Filtrating pressure

    (MPa)

    Weight (kg)

    Dimensions

    (mm)

    (L×W×H)

    XQ1/320-30U 1 320 x 320 30 15 4 0.6 490 1070×570×660
    XQ2/320-30U 2 31 9 528 1295×570×660
    XQ3/320-30U 3 46 14 550 1520×570×660
    XQ4/450-30U 4 450 x 450 60 9 0.6 780 1630×800×900
    XQ6/450-30U 6 91 14 830 1880×800×900
    XQ8/450-30U 8 121 19 880 2130×800×900
    XQ10/450-30U 10 151 24 930 2380×800×900
    XQ12/450-30U 12 182 29 980 2630×800×900
    XQ15/450-30U 15 225 36 1030 2980×800×900
    XQ16/450-30U 16 243 39 1050 3130×800×900
    XQ15/630-30U 15 630 x 630 226 18 0.6 1257 2370×1080×1060
    XQ20/630-30U 20 297 24 1347 2670×1080×1060
    XQ30/630-30U 30 452 37 1693 3320×1080×1060
    XQ40/630-30U 40 595 49 2193 4020×1080×1060





    About our company:



    Our Zhengzhou Toper company is the leading supplier of industrial equipment in China, and also the professional exporter and service provider of filter and separation equipment. from the year 2006, we have exported to more than 100 countries, and accuralated lots of practice experience. so we can give you our best products advise and after-sales service.

    Our products has passed ISO9001 International Quality Management System Certification and is exported to America, Canada, Chile, Bolivia, Indonesia, Malaysia, Israel, Iran, Egypt, Turkey, Romania, Sweden, Finland, etc. about more than 50 countries and area. We have won good reputation depends on our best qualified products and after-sales service. Warmly welcome new and old friends all over the world to come our company for good cooperation with each other!





    Our service:



    1. We have professional person on line to advise you the most suitable type of machie according to your requirement.

    2. Provide you comprehensive.easy-understanding and detail information and technical data about the machie you interested;solve your confusions or questions about the machine

    3. Arrange the schedule if you pay a visit to our factory

    4. Send our technical engineer to your area guid the installation,debugging ,training workers and solve the problems if rquired.





    Different kinds of of our products as below:



    1. Program-controlled automatic filter press

    2. Membrane filter press

    3. Hydraulic compress filter press

    4. Mechanical compress filter press

    5. Jack filter press

    6. Cast iron plate and frame/chamber filter press

    7. Stainless steel plate and frame filter press

    8. Round plate filter press

    9. Cotton cake filter press

    10. Cardboard filter press

    11. DY belt filter press

    12. DYX high pressure belt filter press

    13. DNY rotary drum thickning/dehydrating belt filter press

    14. Triple-belt thickning and dehydrating filter press

    15. SS type three-foot upper discharge centrifuge

    16. SD type three-foot and filter bag hoist discharge centrifuge

    17. PD type filter bag hoist discharge centrifuge

    18. Centrifuge of up discharge, three foot, clean series SSB, SB

    19. SX type manual top discharge centrifuge

    20. PS type manual top discharge centrifuge

    21. SGZ type automatic scraper bottom discharge centrifuge

    22. PGZ type scarper bottom discharge centrifuge

    23. LW series decanter centrifuge

    24. Tubular centrifuge

    25. Multi-layer stainless steel frame filter

    26. Bag filter

    27. Diatomite filter

    28. Filter plate

    29. Filter cloth

    30. Vacuum disc filter



    630x630mm Size Recessed Plate Chamber Filter Press,Manual Compress Filter Press Equipment
